• Diodes (measuring forward drop of diode junctions, i.e., diodes and transistor junctions) and transistors (measuring current gain and other parameters). - Source: Internet
• A multimeter is an indispensable tool for most engineers and technicians when measuring current or voltage. However, when there is a need to measure the power consumption of a device, most multimeters often do not meet the necessary requirements: work at a high sampling rate, sufficient measuring ranges of current, or a quick data transfer to the PC for further analysis. Keysight Technologies’ 34465A/34470A multimeters provide, in addition to measurements of current, voltage, frequency, period, temperature, etc., measurement ranges of current and sampling rate ideal for consumption measurement. - Source: Internet
• This is the basic process how you measure current using a multimeter. The idea is to keep the test probes between the two leads of a load. In our case, the load was the LED bulb so we pointed one probe at the anode and the other at the opposite side. - Source: Internet
• Selecting an amp range(milliamp, microamp) on the multimeter has significant importance. For example, if your fridge uses 3 to 5 amps, then the multimeter should have a range of 10 amps. If the current exceeds the capacity of a multimeter, it might blow its fuse. - Source: Internet
• A multimeter or a multitester, also known as a volt/ohm meter or VOM, is an electronic measuring instrument that combines several measurement functions in one unit. A typical multimeter may include features such as the ability to measure voltage, current and resistance. Multimeters may use analog or digital circuits—analog multimeters and digital multimeters (often abbreviated DMM or DVOM.) Analog instruments are usually based on a microammeter whose pointer moves over a scale calibration for all the different measurements that can be made; digital instruments usually display digits, but may display a bar of a length proportional to the quantity measured. - Source: Internet
• Sometimes it’s quite necessary to test an appliance’s current flow (amp) or a circuit. A multimeter is an excellent cheap device that you can use as a beginner in DIY. Select the AC amp (A〜) setting, connect probes to a circuit, and you’ll get a reading on the multimeter screen. - Source: Internet
• You must be very careful when connecting the multimeter to the circuit. First, turn the circuit off, then connect the multimeter to the desired circuit. This step is also called “Breaking the circuit.” - Source: Internet
• To test amps, you need to be careful and understand what you are doing. Play safe when trying amperage. This is an excellent analogy to the amperage of the current flowing through a circuit. - Source: Internet
• There are multiple settings on the rotary dial of the multimeter, but we’ll select the amps(A), milliamp(mA), or microamp(µA) settings to measure current(amps). The amps symbol on the multimeter is “A.” Whether labeled as a capital “A” or “10A”, the SI unit of the ampere is A. - Source: Internet
• Locate the positive wire leading from the electrical device you’re testing and connect it to the black multimeter tip. If you disconnect the cables on a battery-powered circuit, it will restore its power. Turn on the electricity if you shut it off with a fuse or a switch. - Source: Internet
• Resolution of analog multimeters is limited by the width of the scale pointer, vibration of the pointer, the accuracy of printing of scales, zero calibration, number of ranges, and errors due to non-horizontal use of the mechanical display. Accuracy of readings obtained is also often compromised by miscounting division markings, errors in mental arithmetic, parallax observation errors, and less than perfect eyesight. Mirrored scales and larger meter movements are used to improve resolution; two and a half to three digits equivalent resolution is usual (and is usually adequate for the limited precision needed for most measurements). - Source: Internet
• If the multimeter reads 1 or displays OL , it’s overloaded. You will need to try a higher mode such as 200kΩ mode or 2MΩ (megaohm) mode. There is no harm if this happen, it simply means the range knob needs to be adjusted. - Source: Internet
• Even when using a clamp attachment, your multimeter should include a red and a black probe. The probe will also have a tip on one end to hook into the meter. The black probe, which represents a negative wire, should always be inserted into the COM socket. “COM” means “common,” and if the port isn’t labeled with it, you can get a negative sign instead. - Source: Internet
• Familiarize yourself with the multimeter. Most digital multimeters have a similar look. There are blackjacks for minus or standard wires and three red jacks. One is for measuring voltage and resistance, one is for measuring amperes, and the other is milliamps and microamps. - Source: Internet
• You will now get the reading on the multimeter. Keep in mind that if the scale gives a reading between 1 and 10, it is in amps “A.” And if the measurement has a decimal point, then it is milliamps. - Source: Internet
• A multimeter consists of four input jacks and a rotary dial. The main input jacks are the amps and the milliamp/micro amp terminal. This milliamp/microamp port is next to the amps port and is marked with “mA”. - Source: Internet
• Switch ON the multimeter and select the current function. In the multimeter in the first image above, the DC current function is on the right side of the dial. Select the lowest range (2000µ amperes for this multimeter) - Source: Internet
• Place the multimeter leads into the circuit using a series configuration. The electricity must be redirected to flow completely through the multimeter to obtain an accurate reading. Current should usually move into the red lead and exit the black lead. - Source: Internet
• How you use a voltmeter to measure current is by inserting a current sensing resistor into the circuit, and measuring the voltage across that resistor. The resistor has some small value that does not disturb the quantity of current (at least, not very much). you have to take care that it has enough power dissipation ($I^2R$) for the expected maximum value of $I$. - Source: Internet
• Current measurements tend to be viewed as being more difficult than either voltage or resistance measurements. This is typically because, when measuring current, you have to make sure that all of the current which you want to measure passes through the DMM. This invariably requires that you break your circuit apart at certain points and then insert the DMM at the two ends of those breaks. Of course, after measuring the current, you will also need to re-connect the circuit to its initial condition. - Source: Internet
• Insert the leads into the multimeter connections labeled “current.” Typically, the black lead should be connected to the “common” port, while the red lead is connected to a port that matches the selected current range. This arrangement varies, depending on the unit. Consult the multimeter labels carefully to confirm that the configuration is correct for measuring current. - Source: Internet
• Since the basic indicator system in either an analog or digital meter responds to DC only, a multimeter includes an AC to DC conversion circuit for making alternating current measurements. Basic meters utilize a rectifier circuit to measure the average or peak absolute value of the voltage, but are calibrated to show the calculated root mean square (RMS) value for a sinusoidal waveform; this will give correct readings for alternating current as used in power distribution. User guides for some such meters give correction factors for some simple non-sinusoidal waveforms, to allow the correct root mean square (RMS) equivalent value to be calculated. More expensive multimeters include an AC to DC converter that measures the true RMS value of the waveform within certain limits; the user manual for the meter may indicate the limits of the crest factor and frequency for which the meter calibration is valid. RMS sensing is necessary for measurements on non-sinusoidal periodic waveforms, such as found in audio signals and variable-frequency drives. - Source: Internet
• Select the “Current” setting on the main dial of the multimeter. Choose a current range high enough for the circuit being tested. For example, if the circuit has a current that you estimate to be around five amps, select the “10 amp” setting instead of the “1 amp” option. Choosing a setting that is too low can overload the multimeter. - Source: Internet
• A multimeter is a device that can measure several key details of an electrical circuit. These units are commonly used by professional electricians as well as hobbyists, and they can be purchased from retail stores such as Radio Shack. A modern digital multimeter makes it easy to measure the current flow, expressed in amps; voltage can also be determined. Once the voltage and current are known, you can calculate watts using a simple formula. - Source: Internet
• Once you’ve calculated the highest currents to be tested, locate a lever on your meter. Turn it slightly higher than that figure. If you want to be cautious, turn the dial to the maximum. But if the voltage you’re measuring is too weak, you cannot obtain a reading. You’ll need to lower the scale and retake the task if this happens. - Source: Internet
• Wrap a tiny amount of wire all around the multimeter prongs, or leave enough wire exposed so the alligator prongs can firmly clamp on. If the wire is completely insulated, grip your wire clippers approximately 1 inch (2.5 cm) from the end. Squeeze just enough to cut through the rubber insulation. Then, quickly pull the clippers away to you to extract the insulation. - Source: Internet
• Specifying “display counts” is another way to specify the resolution. Display counts give the largest number, or the largest number plus one (so the count number looks nicer) the multimeter’s display can show, ignoring a decimal separator. For example, a 5½ digit multimeter can also be specified as a 199999 display count or 200000 display count multimeter. Often the display count is just called the count in multimeter specifications. - Source: Internet
• Any ammeter, including a multimeter in a current range, has a certain resistance. Most multimeters inherently measure voltage, and pass a current to be measured through a shunt resistance, measuring the voltage developed across it. The voltage drop is known as the burden voltage, specified in volts per ampere. The value can change depending on the range the meter selects, since different ranges usually use different shunt resistors.[7][8] - Source: Internet
• Feed the wires into the multimeter and connect to the circuit. Do it in the same manner you would on the multimeter clamps. Wrap the clamp around the live or hot wire. It usually is black, red, blue, or another color other than white or green. Unlike using a multimeter, a clamp will not become a part of the circuit. - Source: Internet
• There are two ways to measure current: Direct measurement: Direct measurement measures current at the point where it enters the circuit. For this purpose, you can use a multimeter or clamp meter. Indirect measurement: Indirect measurement measures current at some point outside of the circuit. This can be done by using an ammeter or voltmeter connected to two different points in the circuit. - Source: Internet
• You may see two sockets with the “A,” one marked “A” or “10A,” and one marked “mA .”The “A” or “10A” socket is meant to test current up to 10 amps, while the “mA” socket tests milli-amps up to roughly 300 mA. When you’re unsure which to use, go with the higher “A” or “10A” option to avoid overloading the meter. - Source: Internet
• Locate the power source in the circuit. With the power flowing in the circuit, adjust the dial on the multimeter to measure voltage (AC or DC). Then touch the red positive probe on the multimeter to the positive terminal on the power source and the black negative probe on the multimeter to the negative terminal on the power source. If you were measuring a car battery, it should read about 12 volts DC. - Source: Internet
• If your wires contain prongs, you’ll need to keep them in place when measuring current. You can free up your hands by attaching them to the circuit if they have clamps. However, both types of probes will connect to the meter in the same way. - Source: Internet
• Dynamic current measurements can be quite complex because a range change of the DMM is necessary based on the current level being measured. Keysight has specialized instruments (such as the SMU N6782A) that can simultaneously digitize power, voltage and current without range problems. While this may be a great solution for certain current characterization applications, the option of using a Truevolt multimeter is much more economical. A visual example: this figure describes the discharge of a battery, with a dynamic range of measurement automatically adjusted with the auto ranging function. - Source: Internet
• The range is typical can be extended with the plug-in clamp accouterment. Simply connect the lead generation to the multimeter and connect the other end to the circuit using the multimeter fasteners. Clamp the heated or live wire, which usually is black, red, blue, or another color other than white or green. - Source: Internet
• Confirm that your multimeter fits the number of amps flowing through the circuit before connecting it to it. The estimated maximum amps of most power sources in the nameplate are displayed. At the back of the instrument or in the instruction manual you can find the total amps of the multimeter leads. You might also see how high the scale goes. Do not attempt to test currents higher than the largest scale setting. - Source: Internet
• Wrap the exposed end of the red wire away from the power source with electrical tape. Attach the alligator clips to the wire or wrap the multimeter probe’s tip around it. In any event, to obtain an accurate result, ensure that the wire is tightly secured. - Source: Internet
• (and power supply) with a higher-performance electro-meter, the most versatile and economical solution is to use a stable DC power supply and one of the new Truevolt multimeters from Keysight. These equipments have a low current range for measurements up to 1? A with a resolution of pA and a deviation of less than 100pA. Your - Source: Internet
• Measuring amperage is a measurement of the amount of current flowing through a circuit. Sometimes, it’s necessary to check if an electrical appliance uses more current than it usually does. The main question is: “Can you measure amps with a multimeter?” - Source: Internet
• You must be cautious whether you use a basic multimeter or a digital multimeter. When obtaining electrical measurements, each application with measuring amps poses possible safety dangers that must be considered. Before utilizing any electrical test equipment, individuals should always read the user’s handbook. It is pertinent to learn about proper operating techniques, safety measures, and limitations. (1) - Source: Internet
• To measure the current flows across a circuit, connect the multimeter to complete the course. To begin, turn off the power to the circuit, then disconnect the positive wire (red) from the power source. (2) - Source: Internet
• There may be two sockets with an “A” on them, one labeled “A” or “10A” and the other labeled “mA.” The one with the letters “A” or “10A” is for measuring current up to 10 amps, while the one with the letters “mA” is for measuring milli-amps up to 300 mA. If you’re unsure which level to use, go with the higher “A” or “10A” level to avoid overloading the meter. - Source: Internet
• The other complication of measuring current is that most DMMs have multiple ports for current measurement—our DMM has two; they are labeled A and µA mA. The reason for the two ports is because the current through the DMM has to pass through a fuse. If too much current passes through the fuse, it will blow out. Unfortunately the construction of the DMM is such that, if you use a high capacity fuse in the measurement of a small current, you probably won’t be able to read the current value accurately1. - Source: Internet
